TMC - Navy Transmitter Components

See this web page for complete TMC to Military nomenclature conversion tables

AN/URA-23
AN/URA-23A
includes
   O-503A/URA-23 oscillator
   PP-1796/URA-23 power supply
TMC model SBE-2

manual & spec sheets thanks to K4OZY

ura23-sbe-120301.JPG (42427 bytes) ura23-sbe-120302.JPG (42965 bytes) ura23-sbe-120303.JPG (57594 bytes) ura23-sbe-120304.JPG (75629 bytes)
AN/URA-27 ura27-01.JPG (168509 bytes)
Photos thanks to WA5AVK
Antenna tuner 2-30mc, 1kw
    CU-772/URA-27 tuner
    CU-773/URA-27 directional coupler
    C-2995/URA-27 control monitor


TMC model ATS-50-2

manual & spec sheets thanks to K4OZY


AN/URA-28
AN/URA-28A





SSB/DSB/ISB/AM exciter
O-672/URA-28 + PP-1796


TMC model SBE-3

manual & spec sheets thanks to K4OZY


-- SBE-9 >>>>>>>>>>>>>>>>>>>>

250kc carrier re-insert phase adjust circuit board. Is this the correct  xfmr? This one is clearly a replacement. Please send me info or a photo of an original.

AN/URA-30 sbg1-01.JPG (66331 bytes) "Modulator-Oscillator Group"
Freq. Synthesized SSB/DSB/ISB/AM exciter

Used with AN/URT-19(V)
and as part of:
     AN/FRT-39B
     AN/FRT-39C
     AN/FRT-40B
     AN/FRT-40C
     AN/FRT-62

TMC model SBG-1 comprising:

  • O-714/UR (TMC CBE-1)
    Sideband Exciter
  • AN/URA-31 (TMC CPO-1)
    Oscillator-Power Supply
    (see below)
  • TH-39A/UGT (TMC TIS-3)
    AFSK keyer





TMC model SBG-1

manual & spec sheets thanks to K4OZY

AN/URA-31 cpo1.JPG (60831 bytes) "Oscillator-Power Supply"
Freq. Synthesizer - no exciter
Part of AN/URA-30 Modulator-Oscillator Group

TMC model CPO-1 comprising:

  • AM-2505/UR (TMC CHG-1) or CHG-2
    frequency amplifier
  • O-716/UR (TMC CMO-1)
    controlled master oscillator
  • O-717/UR (TMC CLL-1)
    controlled oscillator
  • O-715/UR (TMC CSS-1)
    frequency standard
  • TH-39A/UGT (TMC TIS-3)
    AFSK keyer
  • CV-928/UR (TMC CHL-1)
    divider chain
  • PP-2562/UR (TMC CPP-2)
    main power supply
  • TMC CPP-1 or CPP-5
    power supply for CHG
TMC model CPO-1

manual & spec sheets thanks to K4OZY

AN/URA-34


70 ohm version of AN/URA-27 Antenna tuner  2-30mc, 1kw



  TMC model ATS-70-2

manual & spec sheets thanks to K4OZY

AN/URA-36
HF amplifier
2-32 mc
TMC model PAL-1KB

manual & spec sheets thanks to K4OZY

C-2749/URT


FSK keyer

manual & spec sheets thanks to K4OZY

c2749a-urt-1105-02.jpg (59591 bytes) c2749a-urt-1105-04.jpg (76126 bytes) c2749a-urt-1105-05.jpg (96254 bytes) c2749a-urt-1105-06.jpg (76293 bytes)
xfk-120301.JPG (35941 bytes) xfk-120303.JPG (61654 bytes) xfk-120304.JPG (75563 bytes) xfk-120305.JPG (56998 bytes)
KY-429/FRT





TMC Model ISK
manual & spec sheets thanks to K4OZY
O-330/FR
O-330A/FR
O-459/URT


-- VFO 2-64 mc TMC model VOX

manual & spec sheets thanks to K4OZY

O-579/URT
O-579A/URT


o579-urt-03.JPG (126216 bytes) Two-tone test generator - used with spectrum analyzer in non-synthesized FRT-39 and FRT-40



TMC model TTG (O-579)

TMC model TTG-2 (O-579A)

manual & spec sheets thanks to K4OZY

AN/FRT-39 tank coil
AN/FRT-39 final tube socket
- -

TMC - 2012 - See www.tmchistory.org for a complete history of the company

(l) TMC historian John Poulton
(r) TMC President Neil de Pasquale
      (son of founder Ray de Pasquale)
Neil and John at TMC HQ building
700 Fenimore Rd.
Mamaroneck NY
TMC HQ building (rear)
700 Fenimore Rd.
Mamaroneck NY
--
