US Navy VHF & UHF Receivers - 1950's

VHF/UHF Receivers

AN/FRR-27
R-518/FRR-27
(similar to FRR-26)
100-156 mc
xtal control
AN/URR-9 urr9-01.JPG (64020 bytes) UHF 225-400 mc AM

manual & 10 channel xtal control

similar to RDZ

double conversion superhet
18.6 & 3.85 mc IF

National

NAVSHIPS 91201

AN/URR-13
AN/URR-13A
AN/URR-13B
AN/URR-13C
R-266()/URR-13()
(formerly RED)
UHF 225-400 mc AM
1 xtal channel or tunable


Crystal pack for URR-13 & URR-35

single conversion superhet

Federal
Espey

NAVSHIPS 91270

AN/URR-21
AN/URR-21A
(R-432/URR-21)


Replaced RCK

VHF 115-156 mc AM

manual or 4 channel xtal control

superhet - 12 mc IF

Note erroneous label as transmitter

Air Associates Inc.


NAVSHIPS 91497
NAVSHIPS 91642(A) - download


urr21a-schem-01.JPG (303796 bytes) urr21a-schem-02.JPG (478732 bytes) urr21a-schem-03.JPG (381406 bytes) urr21a-ac-conn-01.JPG (269302 bytes)
AN/URR-27
AN/URR-27A
(R-516()/URR-27())


VHF 105-190 mc AM
manual or 1 channel xtal control




National URR-27
Clearfield URR-27A

NAVSHIPS 91771

info, schematic, & photos

AN/URR-28(XN-1) urr28-03.JPG (156681 bytes)
info thanks to Ed KD6EU
urr28-02.JPG (218664 bytes) URR-35A redesign with 10 channels - probably not put into production

National

NAVSHIPS 92563

AN/URR-35
AN/URR-35A
AN/URR-35B
AN/URR-35C
AN/URR-35D
R-482()/URR-35()

AN/URR-35A

AN/URR-35C


UHF 225-400 mc AM
manual or 1 channel  xtal control

URR-35D spec sheet

dual conversion superhet
18.6mc & 1.775mc IF

Federal
National
Rauland-Borg
Western Electric

NAVSHIPS 91906 (35)
92022 (35A)
92676 (35C)

urr35-0211-1301.jpg (191504 bytes) urr35-0211-1302.jpg (178591 bytes) urr35-0211-1305.jpg (195708 bytes) urr35-0211-1307.jpg (312504 bytes)
urr35-0211-1308.jpg (339219 bytes) urr35-0211-1303.jpg (162695 bytes) urr35-0211-1304.jpg (187988 bytes) urr35-0211-1300.jpg (32290 bytes)

RCK

RCK Spec Sheets


115-156mc, 4-channel crystal controlled



RDO
RDO Spec Sheets

RDO WW2 Operational Info


Manual NAVSHIPS 900,527



RDZ (CNA-46275)

RDZ Spec Sheets


10 crystal controlled channels

RDZ manuf - National
RDZ-1 manuf - Admiral

--

rdz-0211-1300.jpg (79291 bytes) rdz-0211-1301.jpg (103835 bytes) rdz-0211-1302.jpg (65938 bytes) rdz-0211-1303.jpg (83664 bytes)

RDZ-1 (CQC-46275)


RDZ Power Supply Module
(CNA-20407)

10 crystal controlled channels

RDZ manuf - National
RDZ-1 manuf - Admiral

RDZ Power Supply Module Info
