AN/URT-3 Transmitter Accessory Items

WANTED! - Please let me know if you have any of these items or any other URT-3 parts -  thanks, Nick England K4NYW, Chapel Hill NC



I need the CX-2101/URT Low Level Modulator extender cable -  homebrew version


five 8' extender cables for transmitter cabinet - connector blocks are approx 6" x 3" to 6" x 6"
CX-2100/URT         CX-2101/URT
CX-2102/URT         CX-2107/URT
CX-2108/URT

not shown - five additional 6' cables with smaller Winchester connectors
4 ea. CX-2103/URT
          (Winchester MRE-21x-G)
1 ea. CX-2104/URT
          (Winchester MRE-14x-G)

two 8' extender cables for booster cabinet - connector blocks are approx 6" x 4" & 6" x 6"
CX-2105/URT          CX-2106/URT



 typical drawer rear connector into which the extender cable plugs

 I need the top cover (CW-287/URT-3) for the short booster cabinet
approx 16" x 26" x 1"


also not shown are three 8' and six 6' coaxial extender cables
one CG-246A/U      two CG-960/U
one CG-530/U         five CG-409/U
CB-5/URT antenna capacitor assembly
approx 9" x 13" x 15", 25 lbs.		 scan-08.jpg (217014 bytes)
interior - CB-5/URT antenna capacitor assembly		 scan-13.jpg (180604 bytes)
TS-804/URT antenna control test set
TN-197/URT antenna tuner
aprox 13" x 11" 48", 120 lbs.		 scan-06.jpg (102792 bytes)
interior - TN-197/URT antenna tuner		 scan-12.jpg (187252 bytes)
TS-803/URT antenna tuner test set
C-915/URT remote control
approx 5" x 5" x 11"		 scan-04.jpg (31310 bytes)
interior - C-915/URT remote control		 scan-11.jpg (160641 bytes)
RFO test set - ME-88/U
drawing showing antenna capacitor assembly and antenna tuner		 - -
