Cavite (Sangley Point) Philippines Naval Radio Station

Go to 1929 Los Baņos Receiver Site photos

Go to 1960's Sangley Point Communications Center photos

10 kw 16068 kc crystal controlled transmitter as in new high frequency room - June 1929
New high frequency room (ex- station battery room) showing six station-built high frequency transmitters. Wiring trenches and spaces on left are reserved for TAL and TAG transmitters - June 1929
500 watt A C W high frequency transmitter - June 1929
Naval radio operators on duty in the receiving hut of the Navy's trans-Pacific high power station at Cavite, Philippine Islands

 from 1922 Radio Broadcast magazine thanks to Google



Three 600' towers were built in 1917 - one destroyed in 1941 attack, two demolished in 1945

NPO Cavite, Philippines 1927
NPO Cavite, Philippines 1930 - Sangley Point antenna towers in background
NPO Cavite, Philippines 1934 - Sangley Point antenna towers in background
NPO Cavite, Philippines 1940
NPO tower base
Photo from atop an NPO tower
Photo from atop an NPO tower
NPO Cavite
View looking southwest from coal bunkers on Sangley Point, 10 April 1917. Note riveting stage on center tower. The other two
towers have been completed






View looking northwest, probably from Cavite, following World War I
1930's photo
1941 photo

1945 Tower Demolition by 77th Construction Battalion (Seabees)

Before -
cavite-demolition-1945-text.jpg (177392 bytes) cavite-demolition-1945-00.jpg (130031 bytes) cavite-demolition-1945-02.jpg (102236 bytes)
After
== == ==
